ZTE ZXR10 8900E series switches H1GF48A card provides 48 GE optical interfaces

The H1GF48A card provides the following functions:

• Large switching capacity
It provides 24 GE SFP optical interfaces that support full wire-speed transmission.

• Gigabit out-of-band communication
The MCS module communicates with the CPU of the card through this function, for example, downloading the CPU initialization information.

• EPLD online upgrade
The EPLD of the H1GF48A module provides the online upgrade function by simulating the JTAG interface.

• JTAG test
The H1GF48A module connects to the main chips of line interface cards through a daisy chain to conduct the JTAG test.

• Intelligent detection

Temperature, voltage, and power consumption monitoring circuits are designed on the module to implement real-time monitoring through the IIC bus.

The H1XF16A card provides sixteen 10 GE optical interfaces. It is applicable to the ZXR10 8912E/8908E/8905E/8902E switches, and supports full wired-speed MPLS forwarding.
The H1XF16A card provides the following functions:

• Large switching capacity
It provides sixteen 10 GE SFP+ optical interfaces, and supports full wired-speed MPLS forwarding.

• Gigabit out-of-band communication
The MCS module communicates with the CPU of the card through this function, for example, downloading the CPU initialization information.

• EPLD online upgrade
The EPLD of the H1XF16A module provides the online upgrade function by simulating the JTAG interface.

• JTAG testThe H1XF16A module connects to main chips of line interface cards through a daisy chain to conduct the JTAG test.

• Intelligent detection
Temperature, voltage, and power consumption monitoring circuits are designed on the module to implement real-time monitoring through the IIC bus.
