The Huawei OptiX OSN1800 is a series of box architecture Multi-Service Optical Transport Network (MS-OTN) transmission equipment that supports Time Division Multiplexing (TDM), packet, and Optical Transmission Network (OTN) services over a metro or campus optical network. This equipment enables multiple high-bandwidth services (from 2 Mbit/s to 100 Gbit/s) to be delivered at less cost.
The OptiX OSN 1800 supports resilient, low-latency video transmission,
real-time industrial automation applications, and server-based multimedia
applications. It provides cost-effective transport solutions for power,
medical, Storage Area Networks (SANs), data centers, and video surveillance.
|
Specifications |
OSN 1800 I |
OSN 1800 II |
OSN 1800 II Enhanced |
OSN 1800 V |
|
Dimensions (H x W x D) |
44 mm x 442 mm x 220 mm |
88 mm x 442 mm x 220 mm |
88 mm x 442 mm x 220 mm |
221 mm x 442 mm x 224 mm |
|
Number of Service Slots |
2 slots per cabinet (DC) 1 slots per cabinet (AC) |
7 slots per cabinet (DC) 5 slots per cabinet (AC) |
6 slots per cabinet (DC) |
15 slots per cabinet (DC) 12 slots per cabinet (AC) |
|
Cross-connect Capability |
OTN: 40G ODUk (k=0/1/2/2e/flex) Packet: 120G SDH: 40G (high-order), 5G (low-order) |
N/A |
OTN: 200G ODUk (k=0/1/2/2e/flex) Packet: 160G SDH: 50G (high-order), 20G (low-order) |
OTN: 700G ODUk (k=0/1/2/2e/flex Packet: 700G SDH: 280G (high-order), 40G (low-order) |
|
Number of Wavelengths (maximum) |
DWDM: 80 wavelengths CWDM: 8 wavelengths |
|||
|
Rate per Wavelength (maximum) |
100G/200G |
|||
|
Installation Rack |
19-inch to 23-inch rack, ETSI 300 mm or 600 mm rack |
|||
|
Power Supply |
110V to 220V AC, -48V to -60V DC |
|||
