Hardware Features

Standard & Protocol

IEEE802.11a/b/g/n/ac

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Interface

1 * 10/100/1000Mbps WAN port

1 * 10/100/1000Mbps LAN port

Antennas

2 * Internal antennas

Buton

1 * Reset buton

LED Indicator

1 * Colorful LED indicator(Green,Yellow,Red)

Power

Input: 100-240V—50/60Hz

Output: 12V 1A

Dimensions

91 * 91* 93 mm (3.58 in. x 3.58 in. x 3.66 in)

Wireless Features

Wireless Standards

IEEE802.11a/b/g/n/ac

Wireless Roaming

Comply with IEEE802.11k/v/r

Rate

2.4GHz: 300Mbps

5GHz: 867Mbps

Wireless Security

WPA-PSK/WPA2-PSK(default)

Basic Features

SSID broadcast Beamforming MU-MIMO

Firewall

Forbid TCP/UDP flood atack VPN(PPTP/L2TP/IPsec )pass through

Software Features

Operating Mode

Router Mode, Bridge Mode

Internet Connection Type

PPPoE, DHCP, Static IP

Virtual Server

Port Forwarding, UPnP

Advanced Features

Parental control Guest network Fast roaming

Smart QoS (Gaming, Video & Audio, Download)

Other Features

Auto-sensing Internet connection

Support App management and remote management Firmware upgrade online

Smart assistant Capacity-oriented mode DHCP setings

DNS setings

Others

Operating Temperature

0 °C - 40 °C

Storage Temperature

-40°C ~ 70°C

Operating Humidity

10%~90% RH non-condensing

Storage Humidity

5%~90% RH non-condensing

My Mesh App Requirement

iOS 9.0 or later, Android 4.4 or later

Certification

CE, FCC, RoHS

Package Contents

Mesh WiFi System Power Adapter Installation Guide Ethernet Cable
