Hardware Functions

Standard & Protocol

IEEE802.3, IEEE802.3u, IEEE802.3ab

Interface

1*10/100/1000Mbps WAN port 3*10/100/1000Mbps LAN ports

Antenna

5*6dBi external dual band antennas

Button

1* WPS/Reset Button

Power

Input: AC 100-240V-50/60Hz,0.4A

Output: DC 12V 1A

LED

Sys*1,WAN*1, LAN*1,WiFi/WPS*1

Dimension

(L*W*H) 220x141x49mm

Wireless Functions

Wireless Standard

IEEE 802.11ac/a/n @5GHz IEEE 802.11b/g/n @2.4GHz

Data Rate

2.4GHz: 300Mbps

5GHz: 867Mbps

Frequency

2.4GHz & 5GHz

Basic Features

SSID Broadcast: Enable/Disable;

Transmission Power: high, medium, low

Beamforming+ Technology

MU-MIMO Technology

Wireless Security

WPA-PSK/WPA2-PSK, WPA/WPA2;

Wireless Security: Enable/Disable;

WPS(WiFi Protected Set-up) fast encryption"

Software Function

Internet Connection Type

PPPoE, Dynamic IP, Static IP

Operating Mode

Wireless Router Mode

AP Mode

Universal Repeater mode

WISP Mode

DHCP

DHCP Server

DHCP Client List

DHCP Reservation

Virtual Server

Port Forwaring

DMZ Host

UPnP

DDNS

Supported

Firewall

Supported

VPN

IPsec pass through

PPTP pass through

L2TP pass through

Other Features

Parental Control

Guest Network

Static Routing

MAC address clone

Backup & Restore configurations

Firmware upgrade online or from local

WiFi Schedule

Support IPv6

Support App Management (Speedy WiFi App)

IPTV

Other features

Temperature

Operating Temperature: 0 ℃ ~ 40℃

Storage Temperature: -40 ℃ ~ 70℃

Operating Humidity:10% ~ 90% RH non-condensing

Humidity Storage Humidity: 5% ~ 90%RH non-condensing
