Optical Acess

  • 16 GPON Port OLT 1RU 19
  • 16 GPON Port OLT 1RU 19
16 GPON Port OLT 1RU 1916 GPON Port OLT 1RU 19

16 GPON Port OLT 1RU 19

  • Switching Capacity:Bidirectional 205Gbps
  • PON Interface:16 GPON ports
  • Power Consumption:<105W
  • Product description: 16 GPON Port OLT 1RU 19" GPON OLT
  • INQUIRY

High Performance 16ports GPON OLT, 8xGE or 2*10G SFP+ uplink


OP3616 is a small capacity and enhancement mode cassette GPON OLT, meeting the requirements of ITU-T G.984/G.988 and relative standards of Telecom level GPON, possessing super GPON access capacity, carrier-class reliability and the complete security function. It can satisfy long-distance optical fiber access requirement on account of its excellent management, maintenance and monitoring capability, abundant service features and flexible network mode.OP3616 can be used via CLI and SNMP network management system so as to provide users with the perfect solution.

OP3616 provides 16 downlink GPON port, 8 *GE combo port or 2* 10G SFP+ port. Single PON port can manage 128 ONUs, one pcs OP3616 max to 2048 ONUs. The height is only 1U for easy installation and space saving. OP3616 is suitable for Broadcast three in one, video surveillance network, enterprise LAN, Internet of Things, etc.FTTH network.

Item

OP3616

Switching Capacity

60Gbps

Forwarding Capacity(Ipv4/Ipv6)

104MPPS

Service Port

16*PON port, 8*GE SFP, or 2*10GE SFP+ port

Redundancy Design

Dual power supply

Support AC input, double DC input and AC+DC input

Power Supply

AC: input 90264V 47/63Hz;

DC: input -36V-72V;

Power Consumption

Typical: 56W; Maximum:80W

Dimensions (Width x Depth x Height)

440mm×44mm×340mm

Weight (Full-Loaded)

≤3kg

Environmental Requirements

Working temperature: -5°C55°C

Storage temperature: -40°C70°C

Relative humidity: 10%90%, non-condensing
